大电流贴片保险丝
CMF系列大电流保险丝，2822尺寸，20A-100A，拥有行业领先的体积效率(178mm3)和安全功率密度(506VA/mm3@100A)，约为市场现有产品的3倍，可广泛应用于消费类产品和汽车级产品中。
产品特点：
小体积，高分断能力；
额定电流最高达125A；
低DCR，低功耗；
发生故障时，熔断迅速。
Electrical Characteristics
| Fuse Type | Size | Current Rating | Voltage Rating | Interrupting Rating | Reel Qty | Standard Package | Status | Package Type | RoHS |
|---|---|---|---|---|---|---|---|---|---|
| High Current | 2822 | 100A | 75VDC | 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 125A | 75VDC | 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 20A | 125VDC | 300A @ 125VDC 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape and Reel | Y |
| High Current | 2822 | 30A | 125VDC | 300A @ 125VDC 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 40A | 125VDC | 300A @ 125VDC 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 50A | 125VDC | 300A @ 125VDC 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 60A | 75VDC | 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 70A | 75VDC | 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 80A | 75VDC | 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
| High Current | 2822 | 90A | 75VDC | 1000A @ 75VDC 1500A @ 48VDC | 1000 | 1000 | Active | Tape & Reel | Y |
